3 601 JM4 0K0
Fan Housing
-
Spare part number: 1 600 A02 U6T
Position: 22
Availability: 1
Price group: -
-
Fan Cover
-
Spare part number: 1 600 A02 U6U
Position: 23
Availability: 1
Price group: -
-
Connecting Cable
-
Spare part number: 1 600 A02 U96
Position: 26
Availability: 2
Price group: -
-
Spring Stretching Hook
-
Spare part number: 1 600 A02 U97
Position: 27
Availability: 2
Price group: -
-
Nameplate
-
Spare part number: 1 601 11A A7H
Position: 8
Availability: 1
Price group: -
-
Nameplate
-
Spare part number: 1 601 11A B89
Position: 30
Availability: 1
Price group: -
-
Label GBL 650
-
Spare part number: 1 601 11C 5GG
Position: 9
Availability: 1
Price group: -
-
Armature
-
Spare part number: 1 604 010 BU3
Position: 3
Availability: 1
Price group: -
-
Field
-
Spare part number: 1 604 220 5BM
Position: 2
Availability: 1
Price group: -
-
Motor Housing
-
Spare part number: 1 605 108 2VM
Position: 1
Availability: 1
Price group: -
-
Handle
-
Spare part number: 1 605 132 1AJ
Position: 20
Availability: 1
Price group: -
-
Nozzle
-
Spare part number: 1 605 190 265
Position: 650
Availability: 1
Price group: -
-
Dust Bag
-
Spare part number: 1 605 411 034
Position: 651
Availability: 1
Price group: -
-
Fan
-
Spare part number: 1 606 610 19V
Position: 21
Availability: 1
Price group: -
-
Carbon-Brush Set
-
Spare part number: 1 607 000 F68
Position: 810
Availability: 1
Price group: -
-
Brush Holder
-
Spare part number: 1 607 000 F69
Position: 816
Availability: 1
Price group: -
-
Switch
-
Spare part number: 1 607 200 39P
Position: 4
Availability: 1
Price group: -
-
Hex Nut M6
-
Spare part number: 1 613 300 006
Position: 24
Availability: 1
Price group: -
-
Ball Bearing
-
Spare part number: 1 619 P06 024
Position: 13
Availability: 2
Price group: -
-
Ball Bearing
-
Spare part number: 1 619 P06 024
Position: 13
Availability: 2
Price group: -
-
Protecting Cover
-
Spare part number: 1 619 P06 293
Position: 28
Availability: 1
Price group: -
-
Grommet Ø6,4-Ø7,2X76 MM
-
Spare part number: 2 600 703 017
Position: 6
Availability: 1
Price group: -
-
Power supply cord EU 2,65M 2 X 0,75MM H05VV-F
-
Spare part number: 2 604 460 232
Position: 5
Availability: 1
Price group: -
-
Screw 4X40MM
-
Spare part number: 2 914 201 712
Position: 17
Availability: 4
Price group: -
-
Screw
-
Spare part number: F 002 G31 025
Position: 18
Availability: 8
Price group: -
-
Screw
-
Spare part number: F 002 G31 025
Position: 18
Availability: 8
Price group: -
-
Insulating Cap
-
Spare part number: F 002 G31 065
Position: 16/2
Availability: 2
Price group: -
-
Insulating Cap
-
Spare part number: F 002 G31 065
Position: 16/2
Availability: 2
Price group: -
-
1
Spare parts in list
25 Parts found
Sort by
Description
Pos. 1 | Motor Housing
1 605 108 2VM
-
Pos. 2 | Field
1 604 220 5BM
-
Pos. 3 | Armature
1 604 010 BU3
-
Pos. 4 | Switch
1 607 200 39P
-
Pos. 5 | Power supply cord EU 2,65M 2 X 0,75MM H05VV-F
2 604 460 232
-
Pos. 6 | Grommet Ø6,4-Ø7,2X76 MM
2 600 703 017
-
Pos. 8 | Nameplate
1 601 11A A7H
-
Pos. 9 | Label GBL 650
1 601 11C 5GG
-
Pos. 13 | Ball Bearing
1 619 P06 024
-
Pos. 16/2 | Insulating Cap
F 002 G31 065
-
Pos. 17 | Screw 4X40MM
2 914 201 712
-
Pos. 18 | Screw
F 002 G31 025
-
Pos. 20 | Handle
1 605 132 1AJ
-
Pos. 21 | Fan
1 606 610 19V
-
Pos. 22 | Fan Housing
1 600 A02 U6T
-
Pos. 23 | Fan Cover
1 600 A02 U6U
-
Pos. 24 | Hex Nut M6
1 613 300 006
-
Pos. 26 | Connecting Cable
1 600 A02 U96
-
Pos. 27 | Spring Stretching Hook
1 600 A02 U97
-
Pos. 28 | Protecting Cover
1 619 P06 293
-
Pos. 30 | Nameplate
1 601 11A B89
-
Pos. 650 | Nozzle
1 605 190 265
-
Pos. 651 | Dust Bag
1 605 411 034
-
Pos. 810 | Carbon-Brush Set
1 607 000 F68
-
Pos. 816 | Brush Holder
1 607 000 F69
-
* Prices shown are net prices including VAT
